Inside the pilot sphere
2012-03-25
A view inside the Deepsea Challenger pilot sphere. From left-to-right you can see dual rebreather systems, a marine VHF radio, a socket set (oops), circuit breakers, the acoustic comms interface, and video switching equipment. At the top of frame you can see the tablet PC which functions as the main drive screen, and at the bottom of frame you can see the fiber optic and electrical penetrators through the pressure hull.
|
|
|
|
